| Panels |
|
0.7”
DMD |
| Number
of pixels |
|
786,432
dots (1,024 x 768; h x v) |
| Resolution |
|
550
TV lines (video input), 750 TV lines (DTV 720P input) |
| Lens |
|
1.5-2.2:1
zoom and auto focus with iris |
| Projection
size |
|
40”
(102 cm) to 300” (762 cm) |
| Projection
distance |
|
40”
(102 cm): 1.2 - 1.8m, 100” (254 cm): 3.0m - 4.6m, 300” (762
cm): 9.1 - 13.7m |
| Luminance |
|
3,000
ANSI lumen in High Brightness Mode (Standard Mode)
2,600 ANSI lumen in High Brightness Mode (Eco Mode) |
| Contrast
ratio |
|
2000:1
(High contrast mode) |
| Audio
amplifiers |
|
2W
(mono) |
| Speakers |
|
4
x 2.85cm (oval) x 1 |
| Input
terminals |
|
Computer
RGB component x 2 (15-pin mini D-sub), video x 1 (RCA), S-video
x 1, audio L/R x 1 (3.5 mm mini jack), RS-232C serial x 1
(9-pin mini DIN), LAN x 1 (RJ-45), USB x 1 |
| Output
terminals |
|
Computer
RGB / component x 1 (15-pin mini D-sub), audio L/R x 1 (3.5mm
stereo mini jack) |
| Fan
noise |
|
35
dB (Standard Mode), 32 dB (Eco Mode) |
| Lamp
life*1 |
|
2,000
hours (Standard Mode) / 3,000 hours (Eco Mode) |
| Dimensions
(W x H x D) |
|
310
x 89 x 282 mm (main body only), 310 x 104 x 287 mm (including
adjuster legs and lens) |
| Weight |
|
4.1kg |
| Warranty |
|
3 Year Loan Exxhange |
